Function characteristics:

S outdoor horn box adopts plastic box, exquisite appearance, advantage is that can be applied to high temperature and the temperature difference of the environment, casing corrosion, can withstand the wind the sun wind rain and snow, strong and durable use waterproof design, professional height by waterproof imported PVC basin sperker + treble unit and line impedance matching between a mix of transformer.

S voice appear bright, reduction of voices and music have real properties, acoustic field directivity is good, large scope of amplification strong penetrating power and transmission distance, voice cover broader, has a wide range of frequency response and high efficiency performance.

S working voltage 70 v / 100 v two options designed for long-distance line expansion sound energy make sound pressure evenly and design, this kind of design whether transmission lines far won't change sound quality, and is more suitable for outdoor square, airport, train station, tennis court, swimming pool, a gymnasium, high-grade garden and outdoor places, schools and other large public places all can use.

The performance parameters:

Type  no: TXD - 160. TXD - 260. TXD - 360.

Unit combination: Bass 10 x 1" Bass 12 "x 1 Bass 15 x 1"

The high: 44 core 44 core 51 core

bass: 60 core 170 magnetic 75 190 magnetic fiber 100 220 magnetic fiber

Frequency response: 80 hz - 18 KHZ 65 hz - 18 KHZ 60 hz - 18 KHZ

Sound pressure radiation distance: 200 meters 350 meters 500 meters

The sensitivity: 94 db 96 db 98 db

Maximum sound pressure: 116 db 125 db 128 db

Rated power: 160 w. 260 w. 360 w.

Peak power: 320 w. 520 w. 720 w.

impedance: 8 Ω 8 Ω 8 Ω

Product size (mm): 355 * 355 * 355 520 * 520 * 520  520 * 520 * 520
