The public broadcasting system
Function characteristics:
S 2 MIC input, 3 AUX input, 1 AUX output
S high/bass control, the total volume and the volume of the independent control
S MIC1 has the highest priority mute function, inhibit other input signal automatically
S have a silent sound function, easy to insert the emergency broadcast
S with output short-circuit, overload, overheating, etc protection and warning function
S high-efficiency amplifier circuit with pressure limit circuit to limit the input signal is too large
S constant voltage 70 v, 100 v output, and 4 ~ 16 Ω resistance output, with 100 v output three partitions
S just single machine is a complete small public broadcasting system
The performance parameters:
Model
TA-120
TA-180
TA260
TA-360
TA-500
TA-700
TA-860
The output power
120W
180W
260W
360W
500W
700W
860W
The input sensitivity
Line:
250mV Mic: 2mV
Signal to noise ratio
Line-85db
Mic>70db
The output
70V、100V或4~8ohm
frequency
100HZ-18KHZ
The distortion degree of
<1%
Installation dimensions
485×90×410mm(W×H×D)
